Mini Excavator R32
in stock

Mini Excavator R32

The RIPPA R32 PRO is a heavy-duty 3.2-ton mini excavator built for professional contractors demanding maximum efficiency and durability. Featuring the Kubota V1505 4-cylinder diesel engine, this excavator offers superior digging power, fuel efficiency, and reduced emissions. With an advanced hydraulic load-sensing system, wide operator cab, and a rugged steel undercarriage, the R32 PRO delivers big-machine performance in a compact footprint. Ideal for residential builds, utility trenching, demolition, and commercial construction, it’s a machine built to keep pace with demanding job sites.





Category Tag Brand:
  • Operating Weight: 7,055 lbs (3,200 kg)
  • Transport Length: 146.3 in (3715 mm)
  • Transport Width: 61 in (1550 mm)
  • Transport Height: 97.6 in (2480 mm)
  • Counterweight Ground Clearance: 16.7 in (425 mm)
  • Bucket Width: 17.7 in (450 mm)
  • Boom Length: 87.4 in (2220 mm)
  • Arm Length: 63.8 in (1620 mm)

  • Engine Brand: Kubota

  • Engine Model: V1505

  • Horsepower: 26.5 hp (19.5 kW)

  • Max Speed: 2200 rpm

  • Cylinders: 4

  • Cooling Method: Water-cooled

  • Fuel Type: Diesel

  • Displacement: 91.5 cu in (1.5 L)

  • Bucket Capacity: 0.19 cu yd (0.054 m³)

  • Max Digging Force: 20.3 kN

  • Max Digging Radius: 190 in (4821 mm)

  • Max Digging Depth: 113 in (2870 mm)

  • Max Digging Height: 177 in (4533 mm)

  • Max Unloading Height: 125 in (3181 mm)

  • Max Deflection Angle: 130°

  • Travel Speed: 0.9–3.7 mph (1.5–2.8 km/h)

  • Gradeability: 30%

    • Load-Sensing Hydraulic System – Variable displacement pump for smooth, fuel-efficient operation.

    • Digital LCD Display – Full-color screen shows engine, hydraulic, and temperature metrics in real-time.

    • Auto Idle & Eco Mode – Reduces fuel use by up to 10% during downtime.

    • Spacious Comfort Cab – With air conditioning, wide doors, adjustable seating, and excellent operator visibility.

    • Assistive Attachments – Compatible with breakers, tilt buckets, drills, scarifiers, and rakes.

    • Full Open Bonnet – Simplifies maintenance and improves uptime.

    • Steel-Tracked Undercarriage – Built for durability on tough job sites.

    • Enhanced Safety – Waterproof connectors, divided dozer hose, auto-glow system, and rollover protection options.

  • Main Hydraulic Pump:
    ▸ Load-sensitive variable displacement piston pump

  • Maximum Hydraulic Flow Rate:
    ▸ 99 L/min (26.15 GPM)

  • Hydraulic Pressure:
    ▸ Maximum pressure: 20 MPa (200 bar / 2,900 psi)
    ▸ Rated operating pressure: 18 MPa (180 bar / 2,600 psi)

  • Hydraulic Control:
    ▸ 9-way pilot operated multi-way valve for precise control of boom, arm, bucket, and swing functions

  • Hydraulic Motors:
    ▸ Plunger motor and cycloidal motor with cushioning for smooth operation

  • Hydraulic Oil Cooler:
    ▸ Included to maintain optimal system temperature during heavy use

The R32 PRO is backed by a 3-year machine warranty (parts & service) and a 3-year Kubota engine warranty. All replacement parts are shipped directly to the customer’s address, with service support available through G&J Equipment.

Powerful Performance

Equipped with Kubota V1505 engine, it has the characteristics of high efficiency, low noise and low emission, and complies with EPA4 and Euro 5 environmental standards. The maximum horsepower is 25ps (18.5kW), ensuring strong power output while achieving energy saving and environmental protection.

Convenient all-round maintenance design

The convenient all-round maintenance design not only reduces the downtime and maintenance costs of the excavator, but also extends the service life of the equipment by optimizing the maintenance and repair process. This design provides users with a more efficient and economical operating experience, and is particularly suitable for use in high-intensity operation scenarios, thereby improving the return on investment of the machine.

Built-in air conditioning

The excavator’s built-in air conditioning improves operator comfort, work efficiency and safety, and is suitable for continuous and efficient operation in all weather conditions.

Excellent basic performance

The R32 mini excavator has strong competitiveness in export trade with its core selling points such as high performance, high energy efficiency, easy operation, safety and comfort, easy maintenance, environmentally friendly design, rich configurations and options, and brand trust.
